Behringer MS-5 Analogue Mono Synth

Classic mono synth design

£515.00
Preorder Now

FREE UK Delivery

Free & Next Day delivery to most UK locations when spending over £149

Earn 515 Loyalty Points

You'll get £5.15 to spend on your next order.
stock availability
0 at our Guildford Store
0 at our off-site Warehouse
Want to Click and Collect or try items at our Guildford Store?

The store is open 10am - 6pm Monday to Saturday and 11am - 5pm Sunday and bank holidays.

The stock information shows the quantity of units that are available to purchase at the Guildford store and the quantity of units that are available at our off-site Guildford warehouse. These stock levels are updated in real time.

Our Click and Collect service is available at our Guildford store from 10am - 6pm Monday to Saturday, and 11am - 5pm on Sunday. You can either choose click and collect as your delivery option online or, during store opening hours, call our sales team at 01483 456777 to place a 10% deposit.

If you have placed your order online, you will receive a confirmation email of your order and a separate follow-up text or email to confirm when your item is ready for collection.

Please do not come to the store before you have received the follow-up message, as your order may not yet be ready at the store.

If the only available stock is in our off-site warehouse it can be brought to the store location for you to try - you just need to contact the store within opening hours. Please note any requests received after 3.30pm will not arrive at the store until the following morning.

Please be aware that, unless you have paid a deposit to reserve the item, it will continue to be free, both online and in-store, for another customer to buy. Therefore we would advise you to place a 10% deposit by either using the on-line click and collect service or calling us 01483 456777.

SKU: 0722-AAR86-UK1

You might also need

Product Description

The Behringer MS-5 is a take on a classic design from history. Brilliant for creating powerful bass and exceptionally good at percussive sequenced type lines and experimental type sounds. It’s connectivity options and the ability to use external audio in multiple ways also allows this to be expanded greatly with other external gear such as modular.

Tiltable Front Panel:

The synth can be laid flat or with the synth engine raised to allow you the best access to the sound engine no matter how you’re sat or standing.

Legendary:

The MS-5 builds on a deep history of analogue synths, built way back before the invention of MIDI and owning an instrument simular to this was likened to getting a mortage. The MS-5 brings that legendary tone back into the hands of modern musicians.

Patch free, free the mind:


What you see is what you get, like many other mono synths patch memory is left aside to focus on creativity, what you see on the front panel is what you get, if you want to save a patch you’ll need to either note down or just take a photo of the front panel. You’re forced to create a sound every time you switch the unit on, amazing for creativity and sound design exploration.

Key Features:

  • Fine tuning:
    There are 29 parameters which have adjustable fine tuning on the back of the unit. This can help adjust your synths controls to what you want it to be able to do. For example how the synth pitch’s it’s oscillators, the width of the filter etc. These are not dramatic changes, but they help to make the MS-5 respond in the way you might be more used to.
  • Adjustable ergonomics:
    Do you keep your synth on a rack unit, is it low down on the floor or on a table? Placement of synths in your collection can effect how you can interact with your instrument, the front panel can be tilted to 3 positions or left flat, meaning you can synth noodle in the most comfortable way possible.
  • Connectivity
    The MS-5 has a wide range of options for controlling the synth or using the synth to control other units. Audio can be routed into the synths filter, so hooking up to modular gear or using another unit such as the Behringer Neutron can expand the synths potential. MIDI, CV and even audio can be utilised.

Specifications:

  • Keyboard:
    - Number of Keys: 37
    - Type: Semi Weighted
    - Velocity sensitive
  • Oscillators
    - Number: 2
    - Waveforms: Triangle, Sawtooth (Ramp Down), Square, Pulse
    - OSC-1 Controls: MOD amount, Pulse Width, Waveform, Pitch +/-, Range, Sync Out, Mod mod source Switch, PWM mod source switch.
    - OSC-2 Controls: MOD amount, Pulse Width, Waveform, Pitch +/-, Range, Key Follow switch , Mod mod source Switch, PWM mod source switch.
  • Filters:
    - Switchable between LP, HP + BP
    - LPF Type: 24dB
    - Filter Controls: MOD Source Switch, Mod Mount, Type Selector, Cutoff + Resonance Faders, Keyboard follow, Sensitivity
    - Dedicated Band Pass filter with Frequency, Resonance and Level controls
  • Mixer section:
    - 5 Part mixer section with choice of Noise, VCO-1, VCO-2, Ring Mod, EXT IN, with the choice of routing where they are going to VCF, VCF+BPF, BPF and VCA
  • Noise Generator: White or Pink
  • LFO Sections:
    - Number of LFOS: 2
    - Waveforms: LFO 1 Saw or reverse saw, LFO 2 Triangle, sign or square.
    - Controls: Both include Rate control with LFO 2 including a Delay Time
  • Sample + Hold: Sample Time + Lag Time
  • Ring Mod: Includes source and control selectors
  • Envelope Generators:
    - ADSR: Attack, Decay, Sustain and Release with Fader controls
    - AR: Attach and Release on Fader controls
    - Triggers: Selectable Keyboard, Sample + Hold, LFO-2 or Exteranl Audio to trigger the envs.
  • Performance controls:
    Volume, Panning, Portamento time, Tuning, Portamento amount, Pitch Range, Transpose + Pitch + Mod Bender. Height
  • Connections:
    - Main Output: 2x 1/4" TRS Jacks
    - headphones: 1x 1/4" TRS Jack
    - Controllers: VCF, VCO, Output + Input on 1/4” TS Jacks
    - EXT Input: Trig + Audio 1/4" TS Jacks
    - CV: Keyboard CV output + input, Keyboard Gate Output + Input on 3.5mm TS Jacks
    - MIDI: In, Out + Thru on 5PIN DIN
    - Computer: USB-B (MIDI + Firmware)
  • Fine tuning controls: 29 adjustable tuneable parameters
  • Power: DC input centre Positive
  • Dimensions:
    - Length: 790mm / 31.1”
    - Width: 169mm / 6.7”
    - Height: 483mm / 19”
    - Weight: 12.2kg / 26.8lbs
