SPL Crescendo 8 Mic Pre
Eight-Channel Microphone Preamplifier with 120V technology
FREE UK Delivery
Earn 5280 Loyalty Points
Want to Click and Collect or try items at our Guildford Store?
The store is open 10am - 6pm Monday to Saturday and 11am - 5pm Sunday and bank holidays.
The stock information shows the quantity of units that are available to purchase at the Guildford store and the quantity of units that are available at our off-site Guildford warehouse. These stock levels are updated in real time.
Our Click and Collect service is available at our Guildford store from 10am - 6pm Monday to Saturday, and 11am - 5pm on Sunday. You can either choose click and collect as your delivery option online or, during store opening hours, call our sales team at 01483 456777 to place a 10% deposit.
If you have placed your order online, you will receive a confirmation email of your order and a separate follow-up text or email to confirm when your item is ready for collection.
Please do not come to the store before you have received the follow-up message, as your order may not yet be ready at the store.
If the only available stock is in our off-site warehouse it can be brought to the store location for you to try - you just need to contact the store within opening hours. Please note any requests received after 3.30pm will not arrive at the store until the following morning.
Please be aware that, unless you have paid a deposit to reserve the item, it will continue to be free, both online and in-store, for another customer to buy. Therefore we would advise you to place a 10% deposit by either using the on-line click and collect service or calling us 01483 456777.
SKU: SP-CRESC8
You might also need
Product Description
Crescendo 8 combines the precise sound that German Rundfunk-Technik is famous for with the innovative SPL 120V technology. The internal operating voltage of 120 volts allows Crescendo microphone preamplifiers to break completely new ground. This results in microphone preamps that sound detail-rich, vivid and equally honest.
Crescendo 8 lets microphones shine in a whole new light, because they have never been amplified like this before.
Thanks to the SPL 120V technology, it is almost impossible to overdrive this microphone preamplifier.
All eight channels feature the same range of functions. Besides phantom power (48 V) for condenser microphones, polarity reversal and a PAD switch, they provide the possibility to adjust the VU meter to display very high levels. The gain can be adjusted comfortably and precisely via a high-quality potentiometer. Two outputs per channel allow the signal to be sent to two different devices in parallel. In addition to the extensive feature set and the outstanding technical characteristics, Crescendo 8 convinces with a sonic authenticity that is second to none.
Key Features:
- Built in Output Splitter:
All eight microphone preamps have two parallel outputs each. This allows the signal to be sent to two different devices in parallel. One output each is available as XLR line output. The respective second outputs are available as a DB25 jack. These can for example be ideally connected to a multi-channel AD converter, with the for this kind of device type typical DB25 input. An additional external signal splitter for back-up systems during a recording session is therefore no longer necessary. - Onboard Controls:
Physical controls for parameters such as, Mic Gain, the VU meter, phantom power, pad and polarity reversal. No need to mess around with software and you can keep going with your music making. - Morte Sound Through Innovation:
Our 120V SUPRA operational amplifiers work as current amplifiers, which also offer pure class A operation with over 6 mA quiescent current. We largely dispense with coupling capacitors in order to avoid their sonic disadvantages (diffuse, sloping, loss of dynamics). In order to eliminate DC voltage components active servo circuits are used.
Specifications:
- Analogue input and output; XLR (balanced):
- Maximum output level: 32,5 dBu
- Input impedance: 10 kohms
- Output impedance: 75 ohms
- Frequency range (30 dB Gain): 20 Hz – 100 kHz
- THD + N (30 dB Gain): 0,0089 %
- THD + N (70 dB Gain): 0,30 %
- Noise (A-weighted, 150 ohms, 30 dB Gain): -90,8 dBu
- Noise (A-weighted, 150 ohms, 70 dB Gain): -57,8 dBu
- Equivalent Input Noise, EIN (150 ohms): -127.8 dBu
- Common mode rejection ratio (CMRR, 30 dB Gain): >84 dB - Dimensions:
- Width: 482mm / 19“
- Length: 300mm / 11.8“
- Height: 132mm / 5.2“
- Weight: 9.5kg / 20.94lbs - Power:
- Power required: 230 V: 60 W, 115 V: max. 60W
- Mains voltage (selectable, see fuse chamber): 230 V AC / 50; 115 V AC / 60 Hz
