Rodec ONE With Ministyler Filterbank

The Rodec ONE with Ministyler Filterbank bundle is a powerful modular hub and stereo filter pairing for producers, DJs and live performers who want classic Sherman Filterbank aggression with modern modular flexibility. Combining the legendary analogue filter circuitry of the Ministyler with the high-headroom, balanced I/O and routing power of the Rodec ONE, this compact setup delivers deep sound design, tight integration and rugged portability for studio and stage.

At the heart of the bundle is the Ministyler, a stereo 100-series filter module built around redesigned Sherman Filterbank circuits. It offers continuously morphable low-pass, band-pass and high-pass modes, selectable 12 dB or 24 dB slopes, and self-oscillating resonance that can move from subtle tone shaping to screaming peaks or pure sine oscillation. Paired with a flexible drive stage and dry/wet blend, it excels at everything from gentle analogue warmth to full-on sonic destruction.

The Rodec ONE acts as the control centre, providing balanced stereo inputs and outputs with huge headroom, dedicated phono preamps for turntables, and integration with modular and external gear via CV, MIDI, pulse sync and sidechain inputs. Whether you are filtering a DJ set, mangling drums from a DAW, or patching it into a larger modular rig, the ONE keeps levels clean, routing clear and performance hands-on.

Together, the ONE and Ministyler form a compact, musical and mobile system that invites experimentation. Audio-reactive modulation, CV and FM inputs on the filter turn incoming signals into evolving textures, while the ONE keeps everything locked, synced and ready for performance. It is an ideal bundle for anyone who wants the character of classic Sherman analogue filtering with the practicality of a modern, modular-ready interface.

Legendary Sherman Filterbank Sound

The Ministyler brings the iconic Sherman Filterbank character into a stereo 100-series module. Its redesigned analogue circuitry captures the raw, aggressive tone and flexible response that made the original a studio and live favourite, now optimised for modern modular workflows and stereo processing.

Morphable Stereo Filtering and Self Oscillation

With continuously morphable low-pass, band-pass and high-pass modes and selectable 12 dB or 24 dB slopes, the Ministyler offers precise control over tone and movement. Push the resonance into self oscillation for screaming peaks, harmonic saturation or a controllable sine-wave oscillator that can become a playable element in your patch.

Deep Modulation and Audio-Reactive Movement

CV inputs, FM from the incoming audio and audio-reactive modulation let you drive both filter frequency and mode in highly musical ways. From pulse-driven sweeps and envelope-like cuts to rhythmically synced transitions, the Ministyler behaves like a performance instrument that responds dynamically to your signals.

High-Headroom Modular Hub with Balanced I/O

The Rodec ONE provides balanced stereo inputs and outputs with up to +26 dBU of headroom, preserving punch and clarity even when you push levels hard. With CV control, MIDI and pulse sync, sidechain input and dedicated phono preamps, it anchors modular, DJ and hybrid setups while keeping everything sounding clean, loud and controlled.

• Stereo Analogue Filter with Sherman Circuitry - The Ministyler uses classic Sherman Filterbank architecture adapted for the 100-series format, delivering the same aggressive, musical analogue tone that has defined countless records, now ready for modern modular and stereo applications.
• Morphable Filter Modes with Self Oscillation - Seamlessly sweep between low-pass, band-pass and high-pass responses with selectable 12 dB or 24 dB slopes, then drive the resonance into self oscillation for extreme peaks or pure sine tones that can function as an additional sound source.
• Analogue Drive with Dry/Wet Blend - A powerful gain stage offers up to +30 dB of makeup gain and rich analogue saturation, while the dry/wet control lets you balance clean and processed signals for anything from subtle warmth to heavily distorted, harmonically dense textures.
• Rodec ONE Modular Integration and Connectivity - Acting as a compact control centre, the Rodec ONE provides balanced +26 dBU stereo I/O, CV inputs, MIDI and pulse sync, sidechain input and phono preamps, making it ideal for integrating the Ministyler into modular rigs, DJ setups and hybrid studio systems.

Ministyler Filter Module

• Type: Stereo analogue filter module
• Format: 100-series module
• Filter Modes: Continuously morphable low-pass, band-pass, high-pass
• Filter Slopes: Selectable 12 dB or 24 dB per octave
• Resonance: Self oscillating, capable of sine-wave generation
• Modulation Inputs: CV, FM from incoming audio, audio-reactive modulation
• Modulation Targets: Filter frequency and filter mode
• Drive Section: Analogue gain stage with saturation
• Gain: Up to +30 dB of makeup gain
• Dry/Wet Control: Blend between clean and processed signal
• Compatibility: Rodec 500 to 100 series adapter
• Compatibility: Rodec ONE

Rodec ONE

• Role: Modular interface and compact mixer
• Inputs: Balanced stereo inputs
• Outputs: Balanced stereo outputs
• Output Headroom: Up to +26 dBU
• Phono Inputs: Dedicated phono preamps with grounding for turntables
• Control and Sync: CV inputs, MIDI sync, pulse sync
• Sidechain: Sidechain input for external control
• Design Focus: High-headroom analogue signal path for studio and live use
• Form Factor: Compact, portable unit for modular, DJ and hybrid setups
