RCF EVOX J11 Portable Column PA System - BLACK
Active Three-way Portable Column Speaker
FREE UK Delivery
Earn 1490 Loyalty Points
Want to Click and Collect or try items at our Guildford Store?
The store is open 10am - 6pm Monday to Saturday and 11am - 5pm Sunday and bank holidays.
The stock information shows the quantity of units that are available to purchase at the Guildford store and the quantity of units that are available at our off-site Guildford warehouse. These stock levels are updated in real time.
Our Click and Collect service is available at our Guildford store from 10am - 6pm Monday to Saturday, and 11am - 5pm on Sunday. You can either choose click and collect as your delivery option online or, during store opening hours, call our sales team at 01483 456777 to place a 10% deposit.
If you have placed your order online, you will receive a confirmation email of your order and a separate follow-up text or email to confirm when your item is ready for collection.
Please do not come to the store before you have received the follow-up message, as your order may not yet be ready at the store.
If the only available stock is in our off-site warehouse it can be brought to the store location for you to try - you just need to contact the store within opening hours. Please note any requests received after 3.30pm will not arrive at the store until the following morning.
Please be aware that, unless you have paid a deposit to reserve the item, it will continue to be free, both online and in-store, for another customer to buy. Therefore we would advise you to place a 10% deposit by either using the on-line click and collect service or calling us 01483 456777.
SKU: 13000932
You Might Also Like
Product Description
The RCF EVOX J11 is a powerful yet portable column PA system that delivers exceptional clarity, punch and coverage in a compact, easy to deploy package. Combining a 12 inch bass-reflex subwoofer with a vertical array of twelve 3 inch full-range drivers and a 1.75 inch compression driver, it offers a full, balanced sound that is ideal for bands, DJs, presenters and live performers who need consistent results night after night.
Driven by a 3500 watt Class D amplifier and onboard DSP, the EVOX J11 reaches up to 132 dB Max SPL while maintaining control, definition and headroom. A 120 degree horizontal by 40 degree vertical True Resistive Waveguide ensures your mix is evenly spread across the room, so audiences hear the same clear vocals and detailed music whether they are right in front of the stage or off to the side.
The column and sub are housed in a tough composite enclosure with a quick-fit socket for fast, secure setup. With simple volume and preset controls on the rear panel, you can quickly tailor the system for live performance, club-style playback or spoken word without needing an external processor.
High Output, Compact Footprint
The EVOX J11 delivers up to 132 dB Max SPL from a slim, unobtrusive column and subwoofer stack. This gives you the power to comfortably cover medium-sized venues while keeping your stage tidy and visually discreet, perfect for weddings, corporate events and live music where appearance matters as much as sound.
Three Way Clarity with Deep, Controlled Bass
A 1.75 inch neo compression driver, twelve 3 inch full-range transducers and a 12 inch RCF Precision woofer work together to provide a smooth, natural response from 37 Hz to 20 kHz. The result is tight, controlled low end, articulate mids and clear, present highs that keep vocals intelligible and instruments well defined.
Smart DSP with Practical Presets
The built-in DSP offers dedicated presets for LINEAR/LIVE, CLUB and VOICE, along with a simple volume control. This lets you quickly optimise the system for different applications, whether you need a flat, accurate live sound, a more enhanced club-style response, or maximum intelligibility for speech and presentations.
Road Ready and Easy to Deploy
A robust PP composite cabinet, steel grille, quick-fit pole socket and PowerCON TRUE1 TOP mains connectors make the EVOX J11 ready for regular gigging. The included padded carrying bag for the top speaker helps protect the column during transport, while the lightweight 29 kg total system weight keeps load-ins and load-outs manageable.
Features
- 132 dB Max SPL Output - With up to 132 dB Max SPL at 1 m, the EVOX J11 has ample headroom for demanding live situations, ensuring your mix stays clean and powerful without pushing the system into distortion.
- 3500 W Class D Amplifier with DSP - The onboard dual-channel 3500 watt Class D amplifier delivers fast, efficient power to the column and sub, while integrated DSP manages crossover, protection and presets for reliable performance and consistent sound.
- Wide 120° x 40° Coverage - The 1.75 inch compression driver and True Resistive Waveguide provide a 120 degree horizontal by 40 degree vertical dispersion pattern, giving even coverage across the audience area and reducing dead spots.
- 12” Woofer and 12 x 3” Full Range Drivers - A 12 inch RCF Precision low frequency woofer in a bass-reflex enclosure delivers deep, punchy bass, while twelve 3 inch neo full-range transducers provide detailed mids and highs, creating a coherent, full-range sound from a slim column format.
Specifications
Acoustical
- Frequency Response: 37 Hz - 20000 Hz
- Max SPL @ 1 m: 132 dB
- Horizontal Coverage Angle: 120°
- Vertical Coverage Angle: 40°
Transducers
- Compression Driver: 1 x 0.75 inch neo, 1.75 inch voice coil
- Full Range: 12 x 3.0 inch neo, 1.0 inch voice coil
- Woofer: 1 x 12 inch, 2.5 inch voice coil
Input / Output
- Input Signal: Balanced / unbalanced
- Input Connectors: Combo XLR / Jack
- Output Connectors: XLR
- Input Sensitivity: +4 dBu
Processor
- Crossover Frequencies: 160 Hz / 1800 Hz
- Protections: Thermal, RMS limiter, soft limiter
- Controls: Volume, presets LINEAR/LIVE, CLUB, VOICE
Power
- Total Power: 3500 W peak
- High Frequencies: 1500 W peak
- Low Frequencies: 2000 W peak
- Cooling: Convection
- Connections: PowerCON TRUE1 TOP IN/OUT
Physical
- Cabinet Material: PP composite
- Handles: 1 top
- Pole Mount: Quick-fit socket
- Grille: Steel
- Colour: Black
Dimensions / Weight
- Height: 2285 mm / 89.96 inches
- Width: 400 mm / 15.75 inches
- Depth: 460 mm / 18.11 inches
- Weight: 29 kg / 63.93 lbs
General
- Part Number: 13000932 EVOX J11 220-240 V Black
- EAN: 8024530024147
- Safety: CE compliant
- Top Speaker Padded Carrying Bag Included
