Disaster Area DPC-8EZ Gen3 Switching System for Guitar Pedals
Features 8 Loops & MIDI
FREE UK Delivery
Earn 349 Loyalty Points
Want to Click and Collect or try items at our Guildford Store?
The store is open 10am - 6pm Monday to Saturday and 11am - 5pm Sunday and bank holidays.
The stock information shows the quantity of units that are available to purchase at the Guildford store and the quantity of units that are available at our off-site Guildford warehouse. These stock levels are updated in real time.
Our Click and Collect service is available at our Guildford store from 10am - 6pm Monday to Saturday, and 11am - 5pm on Sunday. You can either choose click and collect as your delivery option online or, during store opening hours, call our sales team at 01483 456777 to place a 10% deposit.
If you have placed your order online, you will receive a confirmation email of your order and a separate follow-up text or email to confirm when your item is ready for collection.
Please do not come to the store before you have received the follow-up message, as your order may not yet be ready at the store.
If the only available stock is in our off-site warehouse it can be brought to the store location for you to try - you just need to contact the store within opening hours. Please note any requests received after 3.30pm will not arrive at the store until the following morning.
Please be aware that, unless you have paid a deposit to reserve the item, it will continue to be free, both online and in-store, for another customer to buy. Therefore we would advise you to place a 10% deposit by either using the on-line click and collect service or calling us 01483 456777.
SKU: DPC8
You might also need
Product Description
Here's what Disaster Area says about the DPC-8EZ:
A bypass looper can streamline your rig in ways you never thought possible – imagine being able to tap one footswitch to go from verse to chorus to bridge of a song, while changing up to eight different effects plus two MIDI devices!
If you already have a MIDI controller, the DPC-8EZ can act as a MIDI “slave” on any available channel. You can even connect two or more DPC-8EZ to control more pedals.
The DPC-8EZ is fully compatible with the Disaster Area Gen3 pedal controllers – connect it to add eight effects loops under MIDI control. The DPC-8EZ can also function as a standalone MIDI controller for up to two devices.
What’s new in Gen3?
The switching system at the heart of the DPC-8EZ is so robust and transparent that we didn’t dare to change it! We did add a few nice new features, though!
- Faster, more powerful 32-bit processor
- Improved USB MIDI capabilities
- User-definable LED brightness (10 levels)
- New MIDI mode controls up to two MIDI devices with program select and tap tempo
- Preset mode now controls MIDI and loops
- Tuner output jack doubles as a MultiJack
- MultiJack functions as MIDI input & output OR double MIDI output
- MultiJack is directly compatible with Chase Bliss, Empress, or Meris pedals
Specifications
- Compact size – 10″ x 2.6″ x 2″ excluding switch caps and jacks.
- No special power supply required – uses less than 120mA, 9V from a Pedal Power 2 or similar.
- 5 footswitches for preset selection or manual effects loop control.
- 48 presets accessible by foot, arranged in four folders with three banks of four presets each.
- 128 presets accessible using an external MIDI controller
- Full MIDI control of presets and effects loops
- 8 effects loops with a custom-designed switching matrix
- MIDI mode controls up to two MIDI devices
- Dedicated insert connection may be assigned to any position in the effects loop section.
- Always-on tuner out with tuner mute, doubles as second MIDI interface
- Status LEDs with user-definable brightness work in any situation from an orchestra pit to full sun.
- Exclusive Z-MODE buffer allows you to tailor the impedance to work with fuzz, vibe, wah, and other impedance-sensitive pedals
- USB connector for MIDI connection and future firmware upgrades (PC and Mac firmware update tools available.)
