Adam Audio Sub8 Pro Studio Subwoofer

The ADAM Audio Sub8 PRO is a professional active subwoofer designed to provide powerful, controlled low-frequency reproduction in compact stereo and multichannel monitoring systems. Combining advanced DSP with a high-excursion 8" woofer, FEA-optimised bass reflex port and efficient Class D amplification, it provides an accurate low-frequency foundation for critical listening and mixing.

The rear panel provides comprehensive connectivity and control, including balanced analogue I/O, AES3 digital input and output, adjustable phase and crossover settings, and a dedicated footswitch input for activating or bypassing bass management. Three operating modes provide flexibility for conventional stereo monitoring and immersive audio workflows.

Network connectivity gives the Sub8 PRO extensive management and calibration options through ADAM Control. The software allows remote adjustment of level, delay and four bands of parametric EQ, alongside firmware updates and support for Sonarworks calibration profiles. This makes it straightforward to optimise the subwoofer for different listening positions and monitoring configurations.

Its robust MDF cabinet features additional internal bracing and a protective steel grille, while the front-firing, front-ported design supports efficient low-frequency reproduction. With a 200 W RMS amplifier and intelligent protection circuitry, the Sub8 PRO combines compact dimensions with dependable professional performance.

• Advanced DSP and Network Control - ADAM Control provides remote access to EQ, delay and level settings, alongside Sonarworks compatibility and firmware updates for continued functionality.
• Professional Connectivity - Balanced analogue I/O, AES3 digital connectivity and a dedicated footswitch input provide flexible integration with professional stereo and multichannel monitoring systems.
• High Excursion 8" Woofer - The low-distortion woofer combines a fibre-reinforced paper cone with an FEA-optimised bass port for controlled and powerful low-frequency reproduction.

Flexible Monitoring Modes:

The Sub8 PRO offers three operating modes designed to accommodate a range of monitoring applications. Stereo mode provides straightforward integration into conventional 2.1 monitoring systems, while LFE mode is tailored towards immersive audio workflows such as Dolby Atmos. Its dedicated 120 Hz LFE cutoff follows Dolby recommendations for LFE channels in Atmos systems. Wide mode allows the Sub8 PRO to reproduce its full frequency range, providing additional flexibility when bass management is handled elsewhere in the signal chain. Four selectable crossover frequencies of 70, 85, 100 and 115 Hz allow the subwoofer to be matched to different main monitors, while adjustable phase settings help achieve accurate integration within the listening environment.

Advanced Calibration and Control:

Ethernet connectivity gives the Sub8 PRO extensive calibration and management capabilities through ADAM Control. The software allows multiple compatible subwoofers and A Series monitors to be controlled remotely, with level, delay and four bands of parametric EQ available for precise system adjustment. This makes it possible to optimise the monitoring system for different listening positions within the studio. The Sub8 PRO also supports Sonarworks calibration, allowing SoundID Reference filters to be uploaded directly to its integrated DSP platform. Firmware updates can also be managed through ADAM Control, allowing new features and improvements to be introduced to the subwoofer over time.

Powerful and Controlled Bass Reproduction:

The Sub8 PRO combines an 8" high-excursion, low-distortion woofer with a powerful 200 W RMS PWM amplifier. Its fibre-reinforced paper cone and elastic rubber surround allow considerable excursion while maintaining mechanical stability, while the ferrite magnet system and demodulation rings help stabilise voice coil inductance. Advanced ventilation of the moving components helps minimise unwanted noise. The FEA-optimised bass reflex port was developed using computer modelling to improve airflow consistency and reduce turbulence. Intelligent peak and thermal limiting works alongside the DSP-controlled amplification to protect the woofer and electronics, while the robust MDF cabinet and internal bracing help reduce unwanted resonances.

• Frequency response at -3 dB: 30 to 228 Hz
• Frequency response at -6 dB: 26 to 300 Hz
• Maximum SPL: 105 dB SPL at 1 m
• Maximum peak SPL: 113 dB SPL at 1 m
• Woofer size: 8"
• Woofer voice coil diameter: 35 mm
• Woofer cone material: Paper
• Woofer amplifier: PWM
• Woofer amplifier RMS power: 200 W at 3 Ohm
• Woofer amplifier peak power: 325 W
• Analogue inputs: 2 x XLR / TRS combi
• Digital input: XLR AES3
• Analogue outputs: 2 x XLR
• Digital output: XLR AES3
• AES3 resolution and sample rate: Up to 24 bit / 96 kHz
• Analogue input impedance: 25 kOhm
• Digital input impedance: 110 Ohm
• Maximum input level: 19 dBu
• AD converter: 24 bit
• Internal sample rate: 96 kHz
• Latency: 4 ms
• Delay range: 0 to 10 ms
• Crossover frequencies: 70, 85, 100 and 115 Hz
• Operational modes: Remote Control, Local / Stereo, LFE and Wide
• Phase settings: 0°, -45°, -90°, 135°, 180°, -225°, -270° and -315°
• Bass management: 70, 85, 100 and 115 Hz
• Footswitch input: Yes, latched TS connection
• Network connection: RJ45 Ethernet
• Communication protocol: AES70 / TCP
• Control software: ADAM Control
• Advanced room adaptation: 4-band parametric EQ
• Third-party calibration compatibility: Sonarworks
• Cabinet design: Front-firing and front-ported
• Cabinet material: Vinyl-wrapped MDF and painted MDF front panel
• Maximum power consumption: 400 W
• Standby power consumption: 2.5 W
• AC input voltage: 100 to 240 V, 50/60 Hz
• Operating temperature: -10°C to +40°C
• Operating humidity: Less than 75% RH, non-condensing
• Warranty: 2 years, extendable to 5 years with product registration
• Included: Sub8 PRO, IEC power cable, quick start guide, safety and warning sheet
