RCF NXL 44-A MK2 Active Two-way Array PA Speaker

The RCF NXL 44-A MK2 is a powerful active two-way array column speaker designed to deliver big-system performance in a sleek, compact footprint. With a 2,100W Class-D amplifier, premium neodymium drivers and advanced DSP on board, it provides up to 135 dB of clean, controlled sound, making it ideal for bands, DJs, clubs and rental companies that need consistent coverage and rock-solid reliability night after night.

Offering a wide 100° horizontal by 25° vertical coverage pattern, the NXL 44-A MK2 projects sound evenly across the audience, whether used as a stand-alone column, pole-mounted over a sub, flown from truss or coupled with a second unit for extended throw. RCF’s FiRPHASE and Bass Motion Control processing ensure impressive clarity and punch from 45 Hz right up to 20 kHz, with tight, musical low end and natural vocal reproduction. Housed in a rugged Baltic birch plywood cabinet with integrated rigging points and Powercon TRUE1 TOP connectivity, it is built to handle demanding touring and installation work.

High-output power with precise control

At the heart of the NXL 44-A MK2 is a 2,100W two-channel Class-D amplifier, delivering up to 135 dB SPL with ease. The ultra-efficient design offers fast transient response, low distortion and minimal power loss, so your mix remains punchy and detailed even at high levels. Convection cooling via a solid aluminium heat exchanger keeps the system stable without the need for a fan, reducing noise and moving parts.

Line array style coverage in a compact column

The vertically advanced horn and column layout provide controlled 100° x 25° coverage, improving intelligibility and reducing unwanted reflections in challenging rooms. You can deploy a single NXL 44-A MK2 on a stand or sub, or cascade two columns for longer-throw applications, making it a flexible solution for anything from corporate events to live bands and DJ sets.

Premium neodymium transducers

RCF designs and builds all drivers in-house, and the NXL 44-A MK2 benefits from a 3 inch titanium dome compression driver with neodymium magnet for extended clarity and low distortion in the high frequencies. Three 10 inch neodymium woofers handle the low and mid range, using an advanced transducer design for improved stability at high currents, fast transient response and efficient heat dissipation, resulting in tight, controlled bass and a solid midrange.

Advanced DSP with Bass Motion Control and FiRPHASE

RCF’s Bass Motion Control technology manages woofer excursion without relying on traditional high-pass filters, allowing the system to reproduce very low frequencies down to 45 Hz while maintaining linearity and preserving phase response. Combined with FiRPHASE filtering, the NXL 44-A MK2 delivers a coherent, time-aligned sound field with excellent stereo imaging and clarity for every listener in the coverage area.

• 2,100W Class-D amplifier with up to 135 dB SPL - A powerful two-channel amplifier provides huge headroom and dynamic impact, keeping your mix clean and controlled even at high volume levels, ideal for demanding live sound and rental applications.
• 100° x 25° constant directivity coverage - The carefully engineered horn and column design deliver even sound distribution across the audience area, improving intelligibility and reducing hot spots and dead zones in real-world venues.
• Premium neodymium driver set - A 3 inch titanium neodymium compression driver and three 10 inch neodymium woofers provide a wide 45 Hz to 20 kHz frequency response with low distortion, tight bass and detailed highs, all in a relatively lightweight enclosure.
• Integrated DSP with Bass Motion Control and FiRPHASE - Onboard processing optimises the system for clarity and punch, managing woofer excursion for deeper, more controlled low end while maintaining phase coherence for a natural, accurate sound image.

Acoustical

• Frequency Response: 45 Hz - 20000 Hz
• Maximum SPL @ 1 m: 135 dB
• Horizontal Coverage Angle: 100°
• Vertical Coverage Angle: 25°

Transducers

• High Frequency: 1 x 1.4 inch neodymium compression driver, 3.0 inch voice coil
• Low Frequency: 3 x 10 inch neodymium woofers, 2.5 inch voice coils

Input / Output

• Input Signal: Balanced / unbalanced
• Input Connectors: Combo XLR / Jack
• Output Connectors: XLR
• Input Sensitivity: -2 dBu / +4 dBu

Processor

• Crossover Frequency: 800 Hz
• Protections: Thermal, excursion, RMS
• Limiter: Soft limiter
• Controls: Linear / 2 Speakers / High-Pass presets, Volume
• DSP: FiRPHASE, Bass Motion Control

Power

• Total Power: 2100 W peak
• High Frequencies: 700 W peak
• Low Frequencies: 1400 W peak
• Amplifier Type: Class-D, 2-channel
• Cooling: Convection
• Mains Connections: Powercon TRUE1 TOP IN/OUT

Cabinet

• Cabinet Material: Baltic birch plywood
• Hardware: 8 x M8 rigging points, 8 x quick lock points
• Handles: 2 side handles
• Pole Mount: 35 mm insert
• Grille: Steel
• Colour: Black

Dimensions & Weight

• Height: 1080 mm / 42.52 inches
• Width: 297.5 mm / 11.71 inches
• Depth: 373 mm / 14.69 inches
• Weight: 33.4 kg / 73.63 lbs

Shipping

• Package Height: 400 mm / 15.75 inches
• Package Width: 1115 mm / 43.9 inches
• Package Depth: 327 mm / 12.87 inches
• Package Weight: 35.5 kg / 78.26 lbs
