Pioneer PLX-CRSS12 Pro Direct Drive Turntable With DVS Control DJ Deck

The Pioneer PLX-CRSS12 is a professional direct drive turntable that bridges the gap between traditional vinyl and modern DVS performance. Supporting both analogue record playback and tone arm free digital control, it gives scratch DJs, turntablists and performance DJs a single deck that can handle every style with rock solid stability and club ready sound.

In Digital Vinyl mode, the PLX-CRSS12 removes the tone arm from the equation entirely, so you can cut, juggle and push your routines harder without worrying about needle skipping. Switch back to analogue and you get the familiar feel of a high quality turntable, evolved from the acclaimed PLX-1000, with refined sound and a robust, matte black design built for the booth and the road.

Performance focused features like the MAGVEL CLAMP, customisable torque and brake settings, built in Performance Pads and an OLED display keep everything you need under your hands and in your eyeline. With native support for Serato DJ Pro and rekordbox DVS, the PLX-CRSS12 slots straight into modern digital setups while still satisfying vinyl purists.

Tone Arm Free DVS Control

In Digital Vinyl mode, the PLX-CRSS12 uses a tone arm free system so the record controls your digital files without relying on a stylus tracking a control signal. The MAGVEL CLAMP locks the record firmly to the platter and translates your movements directly to the software, giving you the feel of vinyl with the reliability of a controller. Even the most aggressive scratch routines stay tight and skip free.

Customisable Feel, Torque and Brake

The PLX-CRSS12 lets you dial in the exact response you want. A dedicated dial on top of the MAGVEL CLAMP adjusts the perceived record weight, so you can fine tune how heavy or light the record feels without swapping slipmats or slip sheets. In the utility menu you can select High, Mid or Low torque to match your preferred start up behaviour, and a front panel switch sets the stopping speed from sharp cuts to long, dramatic slow downs.

Performance Pads and OLED Display

Four MIDI mappable Performance Pads sit just below the platter, putting Hot Cues, samples and other pad modes right where your hand naturally falls. A dedicated button toggles between pads 1 to 4 and 5 to 8, giving you full access without reaching for your mixer. The built in OLED display shows key information such as tempo range, BPM, key and deck number, and also provides quick access to utility settings so you can stay focused on the deck instead of your laptop.

Refined Sound and Robust Build

Building on the PLX-1000 platform, the PLX-CRSS12 is engineered for accurate, high quality sound reproduction from your analogue records. A switching power supply, high mass die cast zinc construction and machined gold plated RCA terminals work together to minimise noise and maximise clarity. The matte black finish, special tone arm coatings and carefully detailed hardware give the deck a premium, understated look that suits any professional booth.

• Tone Arm Free DVS with MAGVEL CLAMP - The innovative Digital Vinyl mode uses the MAGVEL CLAMP to lock your record to the platter and control your digital tracks without relying on the tone arm. This virtually eliminates needle skipping in DVS use, so you can scratch and backspin with total confidence.
• Adjustable Record Feel, Torque and Brake - Quickly tailor the deck to your style with the MAGVEL CLAMP weight dial, three torque settings and a three position brake time switch. Whether you prefer ultra fast starts and sharp stops or a more classic, gradual response, the PLX-CRSS12 adapts to you.
• Integrated Performance Pads and OLED Screen - Four MIDI mappable pads with a 1 to 4 / 5 to 8 toggle put cue and sample control at your fingertips, even if your mixer has no pads. The OLED display keeps key performance data and utility settings in view, reducing the need to look at your computer.
• High Quality Sound and Professional Build - A refined audio path with a switching power supply, high mass die cast zinc chassis and machined gold plated RCA outputs delivers clean, powerful sound. The robust matte black finish and reinforced components are designed to withstand demanding professional use.

General

• Product Type: Professional direct drive turntable with DVS control
• Power Requirements: AC 110 V to 240 V, 50 Hz / 60 Hz
• Power Consumption: 8 W
• Power Consumption (Off): 0.3 W
• Main Unit Weight: 12.2 kg
• Max. External Dimensions (W x D x H): 453 x 353 x 159 mm
• Tolerable Operating Temperature: +5 °C to +35 °C
• Tolerable Operating Humidity: 5 % to 85 % (no condensation)

Turntable

• Drive Method: Servo type direct drive
• Motor: 3 phase brushless DC motor
• Braking System: Electronic brake
• Rotation Speeds: 33 1/3 rpm, 45 rpm
• Rotation Speed Adjustment Range: ±8 %, ±16 %, ±50 %
• Wow and Flutter: 0.15 % or less WRMS (JIS WTD)
• S/N Ratio: 65 dB (DIN B)
• Platter: Aluminium die casting, diameter 332 mm
• Starting Torque (High): 0.45 N·m (4.5 kgf·cm) or more
• Starting Torque (Mid): 0.32 N·m (3.2 kgf·cm)
• Starting Torque (Low): 0.2 N·m (2.0 kgf·cm)
• Start Time: 0.3 seconds (at 33 1/3 rpm)
• Brake Time (Max): 3.5 seconds
• Brake Time (Mid): 1.0 seconds
• Brake Time (Min): 0.5 seconds or less

Tone Arm

• Arm Type: Universal S shape tone arm, gimbal supported bearing structure, static balance type
• Effective Length: 230 mm
• Overhang: 15 mm
• Tracking Error: Within 3°
• Arm Height Adjustment Range: 6 mm
• Stylus Pressure Variable Range: 0 g to 4.0 g (1 scale 0.1 g)

Connectivity and Compatibility

• RCA Terminals: Machined gold plated
• DVS Compatibility: Serato DJ Pro (with compatible DVS mixer), rekordbox (with compatible DVS mixer)
• Performance Pads: 4 MIDI mappable pads with 1 to 4 / 5 to 8 switching
• Display: Built in OLED display for tempo range, BPM, key, deck information and utility settings

Construction and Design

• Chassis: High mass die cast zinc
• Power Supply: Switching power supply
• Finish: Matte black with special coatings on tone arm and selected metal parts
• Clamp: Replaceable MAGVEL CLAMP with dedicated storage area on top of the deck
