CME H12MIDI Pro USB Host/client & 6-in-6-out TRS MIDI With Optional WIDI & Filter, mapper & router

The CME H12MIDI Pro is a compact yet incredibly powerful MIDI hub that keeps even the most complex modern setups under control. With multiple USB host and client ports, plus 6-in-6-out TRS MIDI, it acts as the central brain of your rig, handling routing, filtering and mapping so you can focus on playing, producing and performing.

Whether you are integrating hardware synths, controllers, drum machines or computers, the H12MIDI Pro gives you flexible connectivity in a portable format. Use the free HxMIDI Tools software to create detailed routing presets, then store them on the unit for instant recall on stage or in the studio.

Portable MIDI Brain For Modern Rigs

The H12MIDI Pro is designed to sit at the heart of your MIDI world, without taking over your desk or pedalboard. Its compact footprint hides serious I/O, allowing you to connect multiple controllers, sound modules and computers in one tidy box. Ideal for live performers, touring musicians and mobile producers who need a reliable, travel-friendly MIDI hub.

Deep Routing, Filtering And Mapping

With the free HxMIDI Tools software you can create sophisticated MIDI setups that would be impossible with simple thru boxes. Route any input to any output, filter out unwanted data, and remap channels or messages to suit your workflow. Up to six presets can be stored on the H12MIDI Pro, so your favourite configurations are always ready without needing a computer attached.

Flexible USB Host And Client Connectivity

Six USB-C host ports give you room for multiple class-compliant controllers and sound sources, and can be expanded further using a standard USB hub. A dedicated USB-C client port connects the H12MINI Pro to your computer or mobile device, providing multi-port MIDI in both directions and integrating seamlessly with major operating systems.

Comprehensive TRS MIDI I/O

Twelve 3.5 mm TRS MIDI connections provide 6-in-6-out MIDI I/O for your hardware synths, drum machines and other MIDI devices. This gives you a clean, modern way to hook up multiple pieces of gear without bulky 5-pin DIN connectors, keeping your setup neat while still offering serious connectivity.

• 6x USB-C Host Ports, Expandable - Connect up to 16-in-16-out of USB MIDI via six USB-C host ports, expandable with a standard USB hub. This lets you run multiple controllers and sound modules from one central box, reducing clutter and simplifying your cabling.
• 12x TRS MIDI (6-in-6-out) - Twelve 3.5 mm TRS MIDI connections provide six inputs and six outputs for your hardware. You can integrate a large number of synths, drum machines and other MIDI devices while keeping everything compact and easy to manage.
• Advanced Routing, Filtering And Mapping - Use the free HxMIDI Tools software to create complex MIDI routings, apply filters and build custom maps, then store up to six presets on the unit. This allows you to switch between different live or studio setups instantly, without reprogramming your gear every time.
• USB-C Client Port With Multi-Port MIDI - A dedicated USB-C client connection offers up to 8-in-8-out MIDI to your computer or mobile device, and works with all major operating systems. This makes the H12MIDI Pro a powerful bridge between your hardware rig and your DAW or performance software.

Connectivity

• USB Host Ports: 6x USB-C, up to 16-in-16-out MIDI, expandable via standard USB hub
• USB Client Port: 1x USB-C, up to 8-in-8-out MIDI
• TRS MIDI: 12x 3.5 mm (1/8") TRS MIDI, providing 6-in-6-out MIDI I/O

Control And Software

• Routing: Advanced MIDI routing via HxMIDI Tools software
• Filtering: Configurable MIDI data filters
• Mapping: Custom MIDI mapping options
• Presets: 6 user presets available
• Software: Free HxMIDI Tools configuration software

Power

• Power Options: 5 V USB power
• Additional Power: 9 V DC input
