Chauvet Intimidator Spot 360X IP Stage Lighting

The Chauvet Intimidator Spot 360X IP is a powerful, outdoor-rated moving head designed to keep your show looking sharp whatever the weather. With a 100 W cool white LED, dual rotating prisms, motorised focus and IP65 protection, it delivers crisp gobos, punchy beams and rock-solid reliability for festivals, outdoor stages, architectural lighting and mobile events.

Built around a lightweight yet tough magnalium housing, the Intimidator Spot 360X IP combines professional performance with fast, practical setup. Water resistant power connections, an integrated RF receiver for optional remote control, and a new, smoother home position make it easy to deploy and simple to run. Add in Totem mode to keep beams locked on the action and onboard scene storage, and you have a compact fixture that punches well above its weight.

Outdoor-ready Moving Head Performance

Intimidator Spot 360X IP is purpose-built for outdoor use, with an IP65 rating that protects it from dust and water so your lighting rig can stay in place even when the weather turns. That means less time striking fixtures and more time focusing on your show. Whether it is a festival stage, rooftop bar or open-air event, you get the same consistent performance night after night.

Creative Beam and Gobo Effects

A 100 W cool white LED paired with a 15° beam angle delivers bright, focused output that cuts through ambient light. The rotating, interchangeable gobos let you project detailed patterns, logos and textures, while dual rotating prisms (3-facet round and 5-facet linear) split the beam for wide, dynamic aerial effects. Motorised focus keeps projections crisp at a range of distances, so you can adapt quickly to different venues and throw lengths.

Fast Setup and Flexible Control

Water resistant power input and output connections speed up installation and daisy-chaining, even in challenging environments. The built-in RF receiver allows wireless control via optional RFC or RFC-XL remotes, ideal for quick tweaks without accessing your lighting desk. A new home position reduces whip-around movement when triggering programmes, making your shows look smoother and more professional straight away.

Show-ready Features for DJs and Production

Intimidator Spot 360X IP is packed with features that make it a strong choice for DJs, hire companies and production houses. Totem mode keeps beams focused on the dancefloor or stage, even as the head moves, ensuring your key performance area always looks alive. You can also set, save and recall a custom scene directly from the full-colour LCD display, giving you a reliable fallback or standalone look without needing external control.

• IP65 Outdoor-rated Design - The IP65-rated enclosure protects against dust and water, so the fixture can be used confidently outdoors in changeable weather. This reduces the need for additional housings and minimises downtime caused by unexpected showers.
• 100 W LED with Motorised Focus - A bright 100 W cool white LED and 15° beam angle provide punchy output, while motorised focus keeps gobos sharp from near to far. This lets you adapt to different stage sizes and throw distances without physically moving the fixture.
• Dual Rotating Prisms and Rotating Gobos - Two independent rotating prisms (3-facet round and 5-facet linear) combine with rotating, interchangeable gobos for rich mid-air effects and wide coverage. You can create everything from tight beams to big, immersive looks using a single compact unit.
• Wireless RF Control and Totem Mode - The built-in RF receiver works with optional RFC and RFC-XL remotes for quick, cable-free control, while Totem mode keeps beams locked on the dancefloor or performance area. This makes it easy to maintain engaging, focused lighting without constant desk programming.

General

• Product Type: Outdoor-rated moving head spot
• Housing Material: Magnalium
• IP Rating: IP65
• Approvals: CE, MET, UKCA, ROHS

Light Source

• Type: 1 x LED (cool white)
• Power: 100 W (4.3 A)
• Life Expectancy: 50,000 hours
• Colour Temperature: 15,000 K

Optics

• Beam Angle: 15°
• Lumens: 4,268
• Illuminance (2 m): 23,978 lux
• Illuminance (5 m): 3,836 lux

Colour and Gobo

• Colour Wheel: 8 colours + white, split colours, continuous scroll at variable speeds
• Gobos: 7 + open (6 aluminium + 1 glass)
• Gobo Features: Rotating, interchangeable, indexing, slot-n-lock, continuous scroll at variable speeds
• Gobo Size: 24 mm outside, 20 mm image, 1.1 mm max thickness

Prisms

• Prism 1: 5-facet linear, bi-directional at variable speeds
• Prism 2: 3-facet round, bi-directional at variable speeds

Movement

• Pan: 540°
• Tilt: 270°
• Selectable Pan Ranges: 540°, 360°, 180°
• Selectable Tilt Ranges: 270°, 180°, 90°

Control

• DMX Channels: 8 or 14
• DMX Connectors: 3-pin XLR
• Optional Controllers: RFC, RFC-XL (via built-in RF receiver)
• Onboard Control: Full-colour LCD display with scene set, save and recall
• Modes: Totem mode, built-in programmes

Power

• Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)
• Power and Current (120 V, 60 Hz): 190 W, 2.4 A
• Power and Current (230 V, 50 Hz): 185 W, 1.4 A
• Power Linking: 5 units at 120 V; 9 units at 230 V
• Max Output Current: 12 A (5 units at 120 V, 9 units at 230 V)
• Power Connections: Water resistant power input/output
• Cable Length: 1.5 m (5 ft)

Physical

• Dimensions: 299 x 217 x 406 mm (11.8 x 8.5 x 15.9 in)
• Weight: 10.4 kg (23 lb)
• Bracket: ¼-turn hanging bracket
• Bracket Mounting Hole: 13 mm

Performance

• Strobe Rate: 0 to 20 Hz
• Startup Temperature: -20 °C to 45 °C
• Operating Temperature: -30 °C to 45 °C

Included Items

• Fixture
• Power cord
• PowerCON to bare end (EU only)
• Hanging bracket
• Quick Reference Guide
