Chauvet Intimidator Scan 360 Lazers

The Chauvet Intimidator Scan 360 is a compact, feature-packed LED scanner that delivers razor sharp, whip-fast beams ideal for mobile DJs, bars, clubs and events. With a powerful 100 W white LED, rotating prism and motorised focus, it creates crisp, punchy mid-air effects and detailed gobo projections that cut through any light show.

Designed with practicality in mind, Intimidator Scan 360 offers flexible control options, power linking to simplify your rig, and high-frequency LED dimming for flicker-free performance on camera. Whether you are building a portable party rig or upgrading a permanent installation, this fixture gives you professional results in a robust, easy-to-use package.

Razor Sharp Beams and Gobos

At the heart of Intimidator Scan 360 is a single 100 W white LED that produces bright, focused beams with a 21 degree angle, ideal for cutting through haze and atmosphere. A selection of 7 gobos plus open, including rotating and interchangeable designs, lets you create everything from tight aerial beams to textured projections on walls and dancefloors, all kept pin sharp by the motorised focus.

Dynamic Movement and Prism Effects

The fast-moving mirror head offers 172 degrees of pan and 39 degrees of tilt, giving you wide coverage and energetic sweeps across the room. A crisp, 3-facet rotating prism splits the beam into multiple rays, dramatically increasing coverage and adding depth to your show. Variable rotation speeds let you dial in anything from slow, hypnotic rotations to high-energy, strobing-style effects.

Made for Mobile Performers

Intimidator Scan 360 is built with mobile use in mind, combining a relatively compact footprint with powerful output and flexible power options. Power linking lets you daisy-chain multiple fixtures from a single mains outlet, helping to reduce cable runs and setup time. With 8 or 12 channel DMX modes, it integrates easily into existing lighting rigs and controllers.

Flexible Control and Video Friendly Performance

Control is simple and versatile, whether you are running a full DMX show or keeping things straightforward. The full-colour LCD display allows you to set, save and recall a scene directly from the fixture, while optional IRC-6 remote compatibility enables convenient wireless, non-DMX control. High-frequency LED dimming ensures flicker-free operation on camera, making this scanner a solid choice for livestreams, recorded performances and video content.

• Powerful 100 W LED Scanner - A single 100 W white LED delivers bright, razor sharp beams that stand out in clubs, bars and mobile rigs, giving you professional-level output from a compact fixture.
• Motorised Focus and Rotating Gobos - Motorised focus keeps your gobos crisp at a wide range of distances, while 7 rotating, interchangeable gobos plus open allow you to tailor your look with detailed patterns and aerial effects.
• 3 Facet Rotating Prism - The built-in 3 facet round prism splits the beam into multiple rays and rotates at variable speeds, massively increasing coverage and adding eye-catching movement to your light show.
• Flexible Control and Power Linking - Choose between 8 or 12 channel DMX control, use the full-colour LCD to store a scene, or add an optional IRC-6 remote for wireless operation, while power linking helps streamline cabling when running multiple units.

Optics

• Light Source: 1 LED (white) 100 W (4.2 A)
• LED Life Expectancy: 50,000 hours
• Beam Angle: 21 degrees
• Illuminance: 4,050 lux at 2 m
• Strobe Rate: 0 to 20 Hz

Movement

• Pan: 172 degrees
• Tilt: 39 degrees

Colour and Gobos

• Colours: 8 plus white, split colours, continuous scroll at variable speeds
• Gobos: 7 plus open (6 metal, 1 glass)
• Gobo Features: Rotating, interchangeable, indexing, slot-n-lock, continuous scroll at variable speeds
• Gobo Size (Metal): 19.75 mm outside, 14 mm image, 1 mm max thickness
• Prism: 3 facet round, rotation at variable speeds

Control

• DMX Channels: 8 or 12
• DMX Connectors: 3 pin XLR
• Optional Controllers: IRC / IRC-6 remote
• Onboard Control: Full colour LCD display with manual scene set, save and recall
• Dimming: High frequency LED dimming for flicker free video operation

Power

• Input Voltage: 100 to 240 VAC, 50/60 Hz (auto ranging)
• Power and Current: 147 W, 1.9 A at 120 V, 60 Hz
• Power and Current: 143 W, 1.1 A at 230 V, 50 Hz
• Power Linking: 4 units at 120 V; 7 units at 230 V

Physical

• Size: 255 x 155 x 415 mm (10 x 6.1 x 16.3 in)
• Weight: 5.7 kg (12.6 lb)

Approvals

• Certification: CE

Included Items

• Power cord
• Quick Reference Guide
