NUX NGS-6 Amp Academy Pedal

Nowadays the Amp-less approach is quickly becoming a trend for modern musicians—like guitarists who appreciate a variety of pedals and amps, but don’t have the luxury of a roadie crew to lug all of them around.

Amp Academy inherits NUX TSAC-2K (White-box Amp Modeling) algorithm which delivers the sound and feel of world-class tube amplifiers in a super-portable stomp-box enclosure. Its huge headroom and dynamic range is a pedal friendly platform.

• Pro-Level Amp Modeling with Bias Tweaking.
• 7 Independent moveable signal blocks with Send/Return effect loop.
• Intuitive operation and editor software.
• 1024 samples IR resolution and 3rd party IR loader slot with auto format editor.
• Versatile application scenes with independent 1/4” & XLR IR outs.
• Ultra-low system latency (1.2ms) and premium powerful NXP RT DSP(1GHz).
• Comes with Insert Y-cable for send/return effect loop.
• USB recording interface, firmware update, AmpAcademy editor software.
• Ultra-wide dynamic range: 110dB

Amp Models & IR

• Vintage (Fender Twin Reverb)
• Classic (Fender Vibro King)
• Modern (Mesa Boogie Mark I)
• Brown (Friedman HBE)
• Red (Mesa Boogie Dual Rectifier)
• Iridium (Bogner Uberschall).

The iconic TSAC-2K (WHITE-BOX algorithm) Amp Modeling offers you realistic amp feeling and fast playability response.

• Input Impedance: 1MΩ
• Output Impedance: 1kΩ
• Dynamic Range: 110 dB
• Sampling Rate: 48kHz / 32-bit
• Power：9V DC(Negative tip, Optional ACD-006A adapter)
• Current Draw: less than 300mA
• Dimensions: 105mm(L) x 115mm(W) x 58(H)mm
