Product Description
2 x 120 Watt dual-channel Amplifier provides the perfect solution for commercial and industrial applications requiring great sounding distributed audio coupled with power conservation and reduced operating expense. Capable of delivering high-quality sound over both Low-Z (4/8 Ohm) and High-Z (70/100 V) loudspeaker configurations offering extreme flexibility on every channel. FAD1202 is easy to install and operate – even for non-technical personnel. Simply put, the FAD1202 is ideal-suited for bars & restaurants, retail destinations, hotels, corporate, education or other venues needing background music and/or a public address system.
DDM Ready
Dante replaces point-to-point analog and digital connections with a standard IP network that delivers completely lossless audio, massive channel counts and near infinite signal routing flexibility, all while being incredibly easy to deploy and use.
Dante Domain Manager is network management software that enables user authentication, role-based security and audit capabilities for Dante networks, while allowing seamless expansion of Dante systems over any network infrastructure.
Key Features
- Easy to Install - The FAD1202 comes equipped with rubber feet, enabling the amps to be placed on a desk, shelf or any clear surface without any additional installation requirements. However, optional rack mounting hardware is also supplied, allowing one or several models to be housed and protected inside an enclosure.
- Automatic Power On/Off - The FAD1202 has a flexible power scheme with seamless and automatic power on/off based on the input signal, which reduces consumption when a signal is not present.
- Tamperproof Gain Controls - FAD1202’s input gain controls are placed on the rear panel for tamperproof operation. Available for adjustment – but require a tool when making changes.
Energy Star * Certified
Not only does FAD1202’s direct drive constant power technology provide superior audio performance and reliability, it also consumes less mains power than competing models, which has earned it Energy Star * certification.
This amazing technology makes it possible to design and build powerful amplifier systems that not only save money on the electrical bill, but also reduce the requirements and cost at the installation for the mains supply. In fact, it is likely that installation can be done utilizing the in-place mains infrastructure. This adds up to significant installation and operational savings and protects the environment.
Easy to Hook Up
For connecting a balanced source such as a mixer or audio processor, a standard 3-pin Euroblock Input socket is provided. Loudspeaker Output is provided in the form of a standard 2-pin Euroblock socket.
Output Configuration
Intuitive configuration of the flexible output channels is provided directly adjacent to the rear panel Euroblock output connector with dipswitches, which allow selection of 100 V, 70 V, 8 Ω, or 4 Ω operation. This configures both the maximum voltage of the output and the gain through the device. An individual control engages the built-in high-pass filter, which should be used on all constant voltage systems to avoid saturation on transformer-enabled loudspeakers and to help maintain sound integrity.
Specifications
- Maximum Output Power: 4 or 8 Ω Per Channel, 120 W
- Number Of Output Channels: 2
- Minimum Load Impedance: 4 Ω Mode: 4 Ω, 8 Ω Mode: 8 Ω, 70 V Output Mode: 41 Ω, 100 V, Output Mode: 82 Ω
- Controls: Front: N/A, Rear: Gain Control, Load Config (4Ω / 8Ω / 70 V / 100 V), High-Pass Filter Switch, Reset Button
- Indicators: Front: Power: On (Blue), Standby (Yellow) Limit (Red LED), Per Channel: -1.5 dBFS (Digital) Signal (Green LED), Per Channel: >-63 dBFS (Digital) Fault (Red LED): Overheat, DC Fault, Over Current Etc, Rear: Dante: Identify (Yellow), Clock Sync (White)
- System: Input Transmission Type: Dante, 2 Channels Rx
- Input Connectivity: 1 x RJ45 Ethernet Connector, 1-Port 100 Mbps To Dante Interface
- Input Sensitivity: -2 dBFS (Digital)
- Maximum Input Level: 0 dBFS (Digital)
- Outputs Connectivity: 1 x 4-Pin 5.08 mm Euroblock Connector
- Output Circuit Type: Class D
- Remote Connector: 2 x RJ45 Ethernet Connector
- Performance: Distortion, 1/8 Rated Power: <0.1%
- Frequency Response: 20 Hz to 20 kHz, +0/-1.5 dB
- Crosstalk: >72 dB
- Signal-To-Noise: >101 dBA
- High-Pass Filter: 80 Hz HPF
- Circuit Protection: Cooling: Convection-Cooled, Fanless, Amplifier Protection: Thermal Protection, Over Current Protection, DC Protection, High Frequency Protection, Load Protection: Controlled Start And Shutdown Behaviour, DC-Fault Protection,
- Power Supply, Voltage (Fuse): Main Voltage: 100-240 V∼, 50/60 Hz With Active Power Factor Correction Power Consumption 1/8th Rated Power @ 4 Ω: 70 W, Mains Connector: Standard IEC Connector
- Dimensions / Weight: Dimensions (H x W x D): 44 x 218 x 280 mm (1.7 x 8.6 x 11")
- Weight: 2.6 kg (5.7 lbs)
- Finish: Brushed Black Anodized Aluminum Chassis With Black Painted Steel Bottom
- Approvals: CE, WEEE, cTUVus, PSE, RCM, RoHS, FCC Part 15 Class B, Energy Star 3.0
