IK Multimedia AXE Solo Guitar Audio Interface
192kHz, 2 IN/3 OUT USB Audio Interface with Advanced Guitar Tone Shaping
UK Delivery - From £5.99
Earn 161 Loyalty Points
Want to Click and Collect or try items at our Guildford Store?
The store is open 10am - 6pm Monday to Saturday and 11am - 5pm Sunday and bank holidays.
The stock information shows the quantity of units that are available to purchase at the Guildford store and the quantity of units that are available at our off-site Guildford warehouse. These stock levels are updated in real time.
Our Click and Collect service is available at our Guildford store from 10am - 6pm Monday to Saturday, and 11am - 5pm on Sunday. You can either choose click and collect as your delivery option online or, during store opening hours, call our sales team at 01483 456777 to place a 10% deposit.
If you have placed your order online, you will receive a confirmation email of your order and a separate follow-up text or email to confirm when your item is ready for collection.
Please do not come to the store before you have received the follow-up message, as your order may not yet be ready at the store.
If the only available stock is in our off-site warehouse it can be brought to the store location for you to try - you just need to contact the store within opening hours. Please note any requests received after 3.30pm will not arrive at the store until the following morning.
Please be aware that, unless you have paid a deposit to reserve the item, it will continue to be free, both online and in-store, for another customer to buy. Therefore we would advise you to place a 10% deposit by either using the on-line click and collect service or calling us 01483 456777.
SKU: IP-INT-AXEIOSOLO-IN
You might also need
Product Description
IK Multimedia's AXE I/O audio interface for guitarists now comes in a more compact version, the AXE I/O Solo! With it's single 1/4" input and mic/line input, the Axe I/O Solo is perfect for the guitarist just their guitar or bass at home or live on stage. Also included in Amplitube 4 Deluxe, IK Multimedia's powerful amp modelling software with over 140 models of guitar and bass amps, cabs, pedals, mics, and more.
Sound and Connectivity
The AXE I/O Solo is a great tool for guitarists and bassists looking to only record themselves. It has a single 1/4" input on the front that you can plug your instrument in directly but also an Amp Out for re-amping and a mic/line input on the back for mic'ing an amp. Record your dry signal direct into your DAW, capture the tone of your entire rig, or do both at the same time - great for recording at home or capturing a live set.
With its 24-bit, 192 kHZ sound quality, wide frequency response, and Class A mic preamps, the AXE I/O Solo provides clean and clear sound to ensure your recordings capture all the dynamics and details in your playing. Other connecitivity options include MIDI IN/OUT, external outputs for footswitches/expression pedals, left and right line outs for reference monitors, and a headphone output.
Z-Tone Circuit
While the AXE I/O Solo is designed to preserve your natural sound of your guitar or bass, it also has several tone-shaping tools (two switches and a Z-Tone control knob) to help you get the most out of your sound. The left switch features "Active" and "Passive" options to use depending on which type of pickups are in your guitar. The Passive option is designed to accommodate all passive pickups from low-output single-coils, to high-output modern humbuckers. The Active option is for active pickups, bypassing unnecessary gain stages for a more direct and transparent signal path. The right switch changes the tonal characteristics of the preamp - "Pure" is a transparent and accurate preamp that won't colour the tone, and "JFET" is a Class A JFET input buffer that provides a warmer tone with more midrange focus and subtle harmonic enhancement.
The Z-Tone control knob is a variable impedance control - by increasing the impedance you get a sharper, tighter tone, but when you increase the load you get a thicker, bolder sound. You can make noticeable differences to the tone and characteristics of your guitar or bass' tone with just a simple turn of the impedance control.
Specifications
Common
- Conversion: 24-bit A/D, 24-bit D/A
- Sampling Rate: 44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz, 176.4 kHz and 192 kHz
- Power: USB
- Device Connection: USB B-Type 2.0
- Enclosure: metal sheet
- Line Outputs 1-2 (Monitor) Configuration: Electronically balanced and floating, automatically compensates level when connection is balanced or unbalanced, tip hot.
- Output 3 (Amp output) Configuration: Unbalanced, floating, with selectable ground lift
- Headphones Out - Output impedance: Virtually ideal source (zero Ohms) until clipping
- Mic Input Configuration: Class-A discrete differential microphone preamp, pin 2 hot
- Line Input Configuration: Class-A discrete differential line receiver, tip hot
- Instrument Input Configuration: Multiple topology instrument preamp
- Input impedance, PASSIVE mode: Variable from 1 MOhms down to 2.2 kOhms
- Input impedance, ACTIVE mode: 10 kOhms
Front Panel Connections and Controls
- One 1/4" instrument input jacks
- Two analog potentiometers for Input GAIN
- Two 5 segments input level meter (peak)
- Analog potentiometers for Z-Tone control
- Pick-Up selector (PASSIVE/ACTIVE)
- Preamp topology selector (JFET/PURE)
- +48V phantom power switch
- USB LEDS
- MIDI IN/OUT LEDs
- Monitor knob
- 1/4" headphones output jack
- Master potentiometer for main output control
- 1/4" Amp output jack
Rear Panel Connections and Controls
- MIDI I/O 5-pin DIN connectors
- B-Type USB socket for connecting a computer (Mac/PC)
- 2 x 1/4" TRS External controllers sockets
- 2 x 1/4" TRS Balanced floating line outputs
- 1 Combo socket for MIC input and Line input (auto selecting)
Package Includes
- AXE I/O SOLO
- USB A-Type to USB B-Type connection cable (1.5m/4.32ft)
Dimensions
- Size: 19.5cm x 19.5cm x 5.3cm
- Weight: 1.0kg
Compatibility
- Computers: 64-bit application. Requires a 64 bit CPU and Operating System.
- Mac® (64-bits): Minimal: macOS 10.11 or later. One free USB port.
- Windows® (64-bits): Minimal: Windows 7 or later. One free USB port.
