Alto ZMX862 6-Channel Mixer

This small mixer is great for anyone who needs stereo line inputs plus up to two mics. The Alto ZMX862 would make a good mixer for a DJ, an acoustic solo or duo act or dual singers with a backing track on a CD/MP3 player. These are just three ideas of things you could do with the ZMX862 - versatile despite its size.

Here's what Alto say about the ZMX862

The ZEPHYR ZMX862 is an 8-channel, 2-bus mixer with the right about of inputs, outputs, routing, and EQ for more intimate live performance reinforcement situations. It features two microphone inputs (with Phantom Power) with balanced TRS jacks, a three-band EQ and two AUX sends on each of the two mono channels and the two stereo channels, and even two-track inputs for things such as audio playback. The ZEPHYR ZMX862 is the perfect compact take-anywhere professional mixer.

Versatile Inputs and Outputs

The ZEPHYR ZMX862 is the swiss army knife your creative life needs. Not only can you can plug dynamic, condenser, and wireless microphones into the first two channels, but you also get two stereo channel inputs for keyboards, drum machines, and other instruments. What's more, you can easily plug in your MP3 player, CD players, or audio from a DVD player into the CD/TAPE inputs. But, you also have two AUX sends that you can use to send streams of audio from your mixer to a digital effects unit, stage monitor, TV screen, or any number of sources. Choose the ZEPHYR ZMX862 as the audio central command for your live performances, home studio, or video suite.

Features

• 8 total inputs
• 2 mic input channels with gold plated XLR and balanced line inputs
• 2 stereo input channels with balanced TRS jacks
• Extremely high head room offering extra dynamic range
• 3-band EQ on each channel
• 2 AUX sends pre-channel for external effects and monitoring
• Main output, control room, and headphone outputs

Specifications

Microphone Input

• Electronically Balanced, Discrete Input Configuration
• Frequency Response: 20Hz to 22kHz, +/-1dB
• Distortion (THD&N): <=0.005% At + 4dBu, 1kHz
• Gain range: 0 dB to 50 dB (MIC)
• Maximum Voltage Gain: 70 dB CH MIC INPUTMAIN MIX OUT & TAPE OUT, 80 dB CH MIC INPUTCTRL ROOM & PHONES, 60 dB CH MIC INPUTAUX SEND
• SNR (Signal to Noise Rate ): >=110 dBu
• Phantom power (Mic Pin2/Pin3 And Pin1): +45V~+49V with switch control
• Line Input (Channels 1 & 2)
• Electronically Balanced (SW to LINE)
• Frequency Response: 20Hz to 22kHz, +/-1dB
• Distortion (THD&N): <=0.005% At + 4dBu, 1kHz
• Gain Range: 15 dBu to 35 dBu

Line Inputs

• Electronically Balanced (SW to LINE)
• SNR (Signal to Noise Rate ): >=110 dBu
• Frequency Response: 20Hz to 22kHz, +/-1dB
• Distortion (THD&N): <=0.005% At + 4dBu, 1kHz
• Gain range: -20 dBu to +20 dBu, 60 dB CH LINEMAIN MIX OUT
• Maximum Voltage Gain: 20 dB FX RETURNMAIN MIX OUT, 20 dB RCA TAPE INPUTMAIN MIX OUT

Impedance

• Microphone Input: 3.9k Ohms
• All Other Inputs: 10k Ohms or Greater
• Tape Out: 1k Ohms
• All Other Outputs: 120 Ohms

Equalization

• Mono Channels: High +/-15 dB @12 kHz, Mid +/-15 dB @2.5 kHz, Low +/-15 dB @80 Hz
• Stereo Channels: High +/-15 dB @12 kHz, Mid +/-15 dB @2.5 kHz, Low +/-15 dB @80 Hz

Main Mix Section

• Tape, Aux, Phones Output
• Output level: 0dBu Unbalanced, 1/4" Jacks, Max out +22dBu Unbalanced, 1/4" Jacks Noise (Bus noise): <=-90dB @ 20Hz~22KHz (channel & MAIN level at 0dB, other at minimum, DSP mute)
• Power supply: 18V ~ 1500mA
• Rated Power Consumption: 18W
• Physical Dimension (W/D/H): 202mm/250mm/58mm
• Net Weight: 1.7 kg
• Dimensions: 202mm x 250mm x 58mm
• Weight: 3.75 lb
