Audient ID44 Audio Interface

Get free plugins, software, and more with Audient ARC, click here for more info.

The Classic Audient Sound with Console Mic Pres and Class Leading Conversion

Inspired by 50 years of expertise in analogue hardware design, iD44 is Audient's most powerful audio interface yet. Featuring four Audient console mic pres, class-leading converters, ADAT expandability and more, iD44 delivers the audio performance of an an Audient console on your desktop, giving you the professional sound you deserve.

Key Features

• 20-in, 24-out Desktop Interface
• 4 x Class-A Audient Console Mic Preamplifiers (60dB of gain)
• Class Leading AD/DA Converters
• 2 x ADAT Inputs & Outputs for Digital Expansion
• 2 x Discrete JFET Instrument Inputs
• 2 x Fully Balanced Inserts
• 2 x Independent Stereo Headphone Outputs
• Main and Alt Speaker Outputs
• ScrollControl
• 3 x User Defined Function Keys
• Dedicated Talkback, Dim and Cut Controls
• Low Latency DSP Mixer
• Word Clock Output
• USB2.0 Compliant
• 24bit/96khz
• All-Metal Enclosure
• Power Switch
• Over £500 worth of plugins and software free with ARC

Audient Console Mic Pres

iD44 features four Class-A console mic pres, the same discrete circuit design found in our renowned recording console the ASP8024-HE and throughout our product range. Designed to deliver ultra- low noise and low distortion, the Audient mic pre will provide an accurate reproduction of your source, along with enough analogue warmth to add a bit of character, making it the go to mic pre for any project.

Class leading Converter Technology

Hear your audio more accurately than ever with iD44’s all new high performance AD/DA converter technology. Our next generation converters have been designed to deliver optimised dynamic range, ensuring you hear the most honest and natural translation of your recording. Hear subtle detail, make better mix decisions and experience remarkable clarity from the moment you press play.

Digital Expansion

Equipped with two Optical input and output connectors,  iD44 gives you plenty of options for expansion. Supporting both ADAT and SPDIF, iD44 enables you to add up to 16 channels of mic pres to your setup - perfect for bigger sessions or tracking a live band.

Plug in and Play

As well as offering you 4 channels of mic pre, iD44 has two harmonically rich JFET D.I inputs designed to replicate the input stage of a classic valve amplifier. Simply plug in your guitar, bass or synth whenever inspiration strikes and start recording instantly.

Included in the Box

• Audient id44 Audio Interface
• Standard USB cable
• USB Type-C cable
• Power supply
• Free Software + Plugins

Technical Specifications

Microphone preamplifier

• MIC GAIN: 0 to +60 dB
• LINE GAIN: -10 to +50 dB
• PHANTOM POWER: 48v +/-4v @ 10mA/Channel
• MIC EIN: <-126dBu
• CMRR: >80dB @ 1kHz
• MAXIMUM INPUT LEVEL: +18dBu (+28dBu with pad)
• INPUT IMPEDANCE (Mic): >3kΩ Balanced
• INPUT IMPEDANCE (Line): >10kΩ Balanced
• FREQUENCY RESPONSE: +/-0.5dB 10Hz to 65kHz
• CROSSTALK: <-90dBu @ 1kHz & 10kHz
• THD+N @ 0dBu (1kHz): 0.003% (-96dBu)
• SNR: 96dB
• Pad: -10dB
• HFP: -3dB @ 100Hz, 2nd Order (12dB/Octave)
• XLR: Pin 2 (Hot), Pin 3 (Cold) & Pin 1 (Shield)
• 1/4” JACK: Tip (Hot), Ring (Cold) & Sleeve (Shield)

D.I (Channel 1)

• D.I GAIN: -0 to +60 dB
• MAXIMUM INPUT LEVEL: +10dBu
• INPUT IMPEDANCE: 1MegΩ Unbalanced
• FREQUENCY RESPONSE: +/-0.5dB 10Hz to 50kHz
• THD+N @ 0dBu (1kHz): <0.3%
• SNR: 95dB
• 1/4” JACK: TIP (Hot) & SLEEVE (Shield)

Insert Sends (Mic Pre Out)

• MAXIMUM OUTPUT LEVEL: +18dBu
• OUTPUT IMPEDANCE: <100Ω Balanced
• 1/4” JACK: TIP (Hot), RING (Cold) & SLEEVE (Shield)

ADC Line Inputs (Insert Returns)

• MAXIMUM INPUT LEVEL: +18dBu
• DIGITAL REFERENCE LEVEL: 0dBFS = +18dBu
• INPUT IMPEDANCE: >10kΩ Balanced
• CROSSTALK: >120dB
• FREQUENCY RESPONSE: +/-0.5dB 10Hz to Fs/2
• CROSSTALK: -115dBu @ 1kHz & 10kHz
• THD+N @ -1dBFS (1kHz): <0.0008% (-103dB)
• DYNAMIC RANGE: 121dB A-weighted
• 1/4” JACK: TIP (Hot), RING (Cold) & SLEEVE (Shield)

DAC Outputs (1-4)

• MAXIMUM OUTPUT LEVEL: +18dBu
• DIGITAL REFERENCE LEVEL: 0dBFS = +18dBu
• OUTPUT IMPEDANCE: <100Ω Balanced
• FREQUENCY RESPONSE: +/-0.5dB 10Hz to Fs/2
• CROSSTALK: -118dBu @ 1kHz & 10kHz
• THD+N @ -1dBFS (1kHz): <0.0006% (-104dB)
• DYNAMIC RANGE: 126dB A-weighted
• 1/4” JACK: TIP (Hot), RING (Cold) & SLEEVE (Shield)

Headphone Output (5&6)

• MAXIMUM OUTPUT LEVEL: +14dBu
• DIGITAL REFERENCE LEVEL: 0dBFS = +14dBu
• OUTPUT IMPEDANCE: <50Ω Balanced
• FREQUENCY RESPONSE: +/-0.5dB 10Hz to Fs/2
• CROSSTALK: -110dBu @ 1kHz & 10kHz
• THD+N @ -1dBFS (1kHz): <0.0008% (-103dB)
• DYNAMIC RANGE: 124dB A-weighted
• MAX LEVEL INTO 30ohms: +7.5dBu, 0.003%, THD+N, 2.6Vpk, Power: 225mW or Pavg 112.6mW
• MAX LEVEL INTO 60ohms: +10.2dBu, 0.002%, THD+N, 3.55Vpk, Power: 210mW or Pavg 105mW
• MAX LEVEL INTO 600ohms: +14.2dBu, 0.001%, THD+N, 5.7Vpk, Power: 54mW or Pavg 27mW
• 1/4” JACK: TIP (Left), RING (Right) & SLEEVE (Shield)

Digital i/o

• ADAT 16 CHANNELS: 44.1 – 48kHz
• ADAT 8 CHANNELS (SMUX): 88.2 – 96kHZ
• STEREO S/PDIF: 44.1 – 96kHz

USB2.0 High Speed

• No. of INPUT CHANNELS 20: (4 Analogue, 16 Digital)
• No. of OUTPUT CHANNELS 24: (8 Analogue, 16 Digital)
• Connector: USB Type-C
• Included Cables: 1.5m USB 2.0 Type-C to USB Type-C, 1.5m USB 2.0 Type-C to USB Type-A

iD DSP Mixer Roundtrip (in to out) Latency

• 44.1 kHz: 0.677ms
• 48.0 kHz: 0.625ms
• 88.2 kHz: 0.345ms
• 96.0 kHz: 0.3236ms

DAW Playback Latency @ 32 Sample Buffer for Software Instrument Playback

• 44.1 kHz: ~2.5ms
• 96.0 kHz: ~1.6ms

DAW Roundtrip Software Monitoring Latency @ 32 Sample Buffer (in to out)

• 44.1 kHz: 5.6ms
• 96.0 kHz: 4.2ms

Power Supply

• 12VDC Centre Positive DC Adapter – 2Amps
• Internally conditioned to provide +48VDC, +/-15VDC & low voltage rails for digital processing core & converters. iD44 cannot be bus powered for quality reasons.

Weight

• Unit: 1.75kg
• Packaged: 2.4kg

Dimensions

• Unit: 276mm (w) x 51mm (h) x 174mm (d)
• Packaged: 354mm (w) x 103mm (h) x 229mm (d)
