  • Elektron Analog Four MKII - 4-Voice Polyphonic Tabletop Synth
Home

Elektron Analog Four MKII - 4-Voice Polyphonic Tabletop Synth

6 IN STOCK

£1,279.00£1,189.00

Quantity

Pay Monthly

Loading...

Find out more

Order now for delivery to you on Tue 28th Jun 2022.

6 available

to order online today

2 available

at our Guildford Store

More Information

FREE UK Delivery

Free & next day to most UK postcodes on in-stock items.

Earn 1189 Loyalty Points

Earn one point for every £1 you spend.

Click and Collect

Available to collect by request.

SKU: ANALOGFOURMKII

    Product Description

    The Elektron Analog Four is a fully analog 4 voice tabletop synth module that's ready to put a smile on your face. Elektron are well known for tweaking analog circuitry to get the tone just right - combining it with a comprehensive digital brain to deliver a powerful sequencing and effects engine.

    Key Features

    • Reworked analog circuitry delivering very deep and defined bass
    • Enhanced analog overdrive for more bite and growl
    • Crisp, large OLED screen providing optimal feedback in dimly lit environments
    • Ultra durable back-lit buttons. Rated for 50 million presses
    • Precise, hi-res encoders
    • Quick performance controls
    • Increased amount of dedicated buttons enabling quicker workflow
    • Stereo audio outputs for each voice
    • Expression/CV inputs for external control of Analog Four MKII parameters
    • Overbridge with higher bandwidth
    • Premium cast aluminium enclosure

    youtube video thumbnail

    Get ready for MKII

    The Analog Four has been taken back into the workshop and taken apart to create an entirely new MKII Analog Four. The analog circuitry has been reworked and the overdrive enhanced with more attitude than its predecessor.

    A lovely touch is that the MKII synth features a new OLED screen, so that you can easily delve into the Four's digital parameters. To help with this, Elektron have also added extra buttons and even some CV inputs for improved external control.

    Here's what Elektron say about the Analog Four MKII:

    Analog bliss

    Organic, warm, chaotic, exact, and everything in between. Moulding your own unique analog sounds is simple. Program them with precision, or feel free to design as you go. The sonic range is so vast entire tracks can be created from scratch.

    From sounds to songs

    Four synth tracks and an intuitive step sequencer enable you to easily create and layer melodies. Then play back your composition and immediately reshape it. Change notes, alter sounds, add effects. Something beautifully unique will emerge every single time.

    Modular control

    Not only a splendid synthesizer, the Analog Four can also make other gear sing. Thanks to the CV/Gate and DIN sync outputs, external analog gear can be controlled in great detail. Make any modular or vintage synthesizer rig come truly alive.

    Included in the box

    • Power Supply PSU-3b
    • Elektron USB cable
    • Quick Guide

    Technical Specifications

    Synth voice features (×4)

    • Fully analog signal path
    • 2 × analog oscillators
    • Variable waveshape on all waveforms
    • Oscillator AM and Sync modes
    • 2 × sub-oscillators
    • 1 × noise generator
    • 1 × 4-pole analog lowpass ladder filter
    • 1 × 2-pole analog multi-mode filter
    • 1 × analog overdrive circuit
    • Filter feedback
    • 2 × assignable LFOs
    • 1 × dedicated vibrato LFO
    • 2 × dedicated waveshape LFOs
    • 1 × amp envelope
    • 2 × assignable envelopes
    • 2 × dedicated LFO fade envelopes
    • 1 × dedicated noise fade envelope
    • 1 × dedicated vibrato envelope
    • 1 × dedicated autobend envelope
    • 3 × individual effect sends

    Polyphony

    • Up to 4 notes of polyphony
    • Up to 4 part multitimbrality
    • Up to 4 note unison playback

    Storage

    • 128 Projects
    • 4096 Sounds (+Drive Sound Library)
    • 128 Sounds per Project (Project Sound Pool)
    • 128 Kits per Project
    • 128 Patterns per Project
    • 16 Songs per Project

    Sequencer

    • 4 synth tracks
    • 1 FX track
    • 1 CV/Gate track
    • Sequencer MIDI Out
    • Up to 64 steps per pattern
    • Individual length per track
    • Individual scale per track
    • 6 × arpeggiators
    • Parameter locks
    • Step Recording mode
    • Trig preview
    • Trig probability
    • Instant Pattern, Kit and Sound reload
    • Live friendly Performance mode
    • Swing, slide, accent
    • Track transpose
    • Micro timing
    • Sound-per-step change
    • Full real-time control

    Send effects

    • Wideshift Chorus
    • Saturator Delay
    • Supervoid Reverb

    Hardware

    • 128 × 64 pixel OLED screen
    • MIDI In/Out/Thru with DIN Sync out
    • 2 × 1/4” impedance balanced main audio out jacks
    • 4 × 1/4” separate stereo voice output jacks
    • 2 × 1/4” audio in jacks
    • 1 × 1/4” stereo headphone jack
    • 4 × 1/4” CV/Gate outputs
    • 2 × 1/4” CV/Expression inputs
    • 48 kHz, 24-bit D/A and A/D converters
    • Flash-EEPROM upgradable OS
    • Electrically isolated USB 2.0 Hi-Speed port

    Balanced audio outputs

    • Headphones out level: +19 dBu (55 Ω)
    • Main outputs level: +19 dBu
    • Output impedance: 440 Ω unbalanced

    Unbalanced audio inputs

    • Input level: +19 dBu maximum
    • Audio input impedance: 9 kΩ
    • CV/Expression inputs
    • Input voltage on tip: -5 V–+5 V. Supplies +5 V on ring
    • Accepts CV, Expression pedals

    CV outputs

    • Voltage range: -10 V–+10 V.
    • Digital S/N ratio: 102 dBFS (20–20.000 Hz)

    Electrical specifications

    • Unit power consumption: 15 W typical, 20 W maximum.
    • Recommended power supply: 12 V DC, 2 A

    Physical specifications

    • Aluminum enclosure
    • Dimensions: W385 × D225 × H82 mm (15.2 × 8.85 × 3.3″) including knobs, jacks and feet
    • Weight: approximately 2.4 kg (5.3 lbs)

    Miscellaneous

    • Overbridge enabled
    • Class Compliant USB Audio
    • 3 year Elektron warranty
    Specifications
    Brand
    Elektron
    Digital/Analogue
    Analogue
    Polyphony
    Polyphonic
    CV Compatible
    Yes
    Trade Doubler Group ID
    13360
    Loyalty Points

    Earn loyalty points whenever you shop at Andertons. Points can be earned and used online, in store or over the phone: earn and use points however you choose to shop! No need to sign up - points are added automatically when you make a purchase! The more you shop, the more you save, so start earning points now!

    What are points worth?

    One point is worth a 1p discount, and there's no limit on the number of points used per purchase! For example, if you have 1000 points, you can redeem them for a £10 discount on any purchase.

    How many points will I earn when I shop?

    We display the number of points available for a product on the product's page on our website. Normally we'll give you one point for every pound you spend, but watch out for double and triple points deals for even more savings!

    Delivery

    Here at Andertons Music Co. we believe that we stock some of the best musical equipment in the world. That's why we want to make it as quick and easy as possible for you to get your order, safe and sound!

    We offer a wide range of delivery options to help fit around your busy lifestyle without compromise. This includes free, named-day delivery for most UK postcodes on orders over £99 which are in stock, Saturday & Sunday deliveries, and competitive delivery rates worldwide.

    Please note: Some UK postcodes including remote areas and Northern Ireland are subject to charges.

    You can find full details about the services we offer, including details on our international delivery charges, on our main delivery page. Click here to read more.

    Customer Reviews

    5.0

    9 reviews

    Value

    Looks

    Durability

    Sound

    Trusted Customer15th May 2022

    Great synth, all in one multitimbral box of amazing tricks, also built like a brick.

    Value 5Looks 5Durability 5Sound 5

    Mr Alexander Eve5th Sep 2021

    Value 5Looks 5Durability 5Sound 5

    Trusted Customer25th Jun 2021

    I usually find hardware synths kind of underwhelming given how spoiled we are with VSTs these days, but the A4 really makes you realise just how good hardware can be. Elektron workflow is not for everyone, perhaps—and not everyone wants a synth that is basically sequencer driven. But if that appeals, this is worth every penny.

    Value 5Looks 5Durability 5Sound 5

    Mr Jeremy Carver9th Mar 2021

    Value 5Looks 5Durability 5Sound 5

    Mr Kenneth Goulson22nd Feb 2021

    Value 4Looks 5Durability 5Sound 5

    Mr John Crump28th Oct 2020

    Value 5Looks 5Durability 5Sound 5

    Trusted Customer1st Jun 2020

    Elektron Analog four Mk 2 Fantastic sounding four track synthesizer 2 osc 2 sub osc

    Value 5Looks 5Durability 5Sound 5

    Trueyorky1st Apr 2020

    I am a sucker for Elektron products and the Analog Four MKII is amazing :)

    Value 5Looks 5Durability 5

    Shaun2nd Jan 2019

    Loving this so far. I had bought a keys a couple of years ago, but never really "got it". However, as a wee box this much better to use and interface is fantastic. Get some mad sounds out of it. I use a digtakt for drums and this is ideal companion for bass and lead lines. But pricey I guess but it is a fantastic little unit and reasonably easy to navigate around.
