  • Audient EVO 16 24-in 28-out USB-C Audio Interface
Home

Audient EVO 16 24-in 28-out USB-C Audio Interface

Loading...

£399.99

Quantity

Register your interface & receive a bundle of free software!

Pay Monthly

Loading...

Find out more

Order now for delivery to you on Fri 12th Aug 2022.

7 available

to order online today

3 available

at our Guildford Store

More Information

FREE UK Delivery

Free & next day to most UK postcodes on in-stock items.

Earn 400 Loyalty Points

Earn one point for every £1 you spend.

Click and Collect

Available to collect by request.

SKU: EVO16

    ARC: Free Software

    Register your Audient interface and receive a bundle of leading software completely free! Take your music to the next level with Cubase & Cubasis LE 3, Retrologue 2, M-tron Select, Torpedo Wall of Sound, Produce Like a Pro, Loopcloud, Waldorf Edition 2 LE and Sonarworks. Find out more here.

    Product Description

    The Audient EVO 16 Audio Interface is a studio powerhouse, designed from the ground up to ensure users have the easiest experience possible while offering enough I/O firepower to handle even the biggest of recording sessions!

    Featuring 8 award winning EVO preamps alongside Audient's advanced converter technology ensures your recordings sound the best they possibly can. Intelligent mic preamps set their own levels with Smartgain and make use of the new, ground-breaking Motion UI control system.

    Key Features

    • 8 x EVO Mic Preamps
    • 2 x JFET Instrument Inputs
    • 2 x Independent Headphone Outputs
    • 8 x Line Outputs
    • 2 x Optical Inputs
    • 2 x Optical Outputs
    • Multi-Channel Smartgain
    • 'EVO Motion UI' Control System
    • High-Res LCD Screen
    • One Knob Centralised Control
    • Ultra Clear Metering
    • Input/Output Control
    • Channel Status Indication
    • Programmable Function Button
    • Ultra-Low Latency Software Mixer
    • Monitor Control
    • Audio Loop-back
    • Word Clock Output
    • USB2.0 (USB-C Connection)
    • 24bit / 96kHz

    youtube video thumbnail

    Top-class Mic Preamps featuring Smartgain Technology

    With 25 years of experience behind them, Audient's mic preamps have been designed to deliver the most accurate, clean and true to source version of your audio no matter what you're recording. The EVO Preamp technology has the advantages of an analogue mic preamp combined with digitally controlled precision which gives you the ability to set your gain with pin-point accuracy!

    Powered by Audient's lightning fast Smartgain algorithm, Smartgain uses advanced peak analysis to automatically analyse and set your gain to the perfect level in under 20 seconds! All you need to do is set up your mics, engage Smartgain and the EVO 16 will take it from there. Set the gain for all 8 Mic preamps with the touch of a button!

    Future-proof your Setup

    The EVO 16's optical inputs and outputs have you got covered for sessions of any size! Supporting both ADAT and SPDIF, you can add up to 16 channels of mic preamps to your setup, giving you plenty of options for expanding your recording capabilities down the line.

    Monitor your settings via the LCD Screen

    All details and adjustments made are displayed in real-time via the TFT backlit LCD screen, allowing you to navigate hardware features and make changes on the fly with ease. Take full control of your recording without ever needing to look at your computer!

    Specifications

    Microphone Preamplifier

    • Mic Gain Range: 58 dB
    • Line Gain Range: 58dB with -10dB Pad
    • Phantom Power: 48v +/-4v @ 10mA/Channel
    • CMRR: >80dB @ 1kHz
    • Maximum Input Level: +16dBu
    • Input Impedance (Mic): >3kΩ Balanced
    • Input Impedance (Line): >10kΩ Balanced
    • Frequency Response: +/-0.5dB 10Hz to 40kHz
    • Crosstalk: <-105dBu @ 1kHz <-103 @ 10kHz
    • THD+N @ 0dBu (1kHz): <0.0015%
    • SNR: 100dB
    • Mic EIN: <-127.5dBu
    • XLR: Pin 2 (Hot), Pin 3 (Cold) & Pin 1 (Shield)
    • 1/4" Jack: TIP (Hot), RING (Cold) & SLEEVE (Shield)

    D.I.

    • D.I Gain Range: 58 dB
    • Maximum Input Level:  +10dBu
    • Input Impedance: 500k
    • THD+N @ 0dBu (1kHz): <0.1%
    • SNR: 100dB
    • Frequency Response: +/-0.5dB 10Hz to 20kHz
    • 1/4” Jack: TIP (Hot) & SLEEVE (Shield)

    Analogue To Digital Converter

    • Digital Reference Level: 0dBFS = +10.5dBu
    • Frequency Response: +/-0.5dB 10Hz to Fs/2
    • Crosstalk: -125dBu @ 1kHz & 10kHz
    • THD+N @ -1dBFS (1kHz): <0.001%
    • Dynamic Range: 112.5dB A-Weighted
    • Digital To Analogue Converter
    • Maximum Output Level:  12dBu
    • Digital Reference Level: 0dBFS = +12dBu
    • Output Impedance: <50Ω
    • Frequency Response: +/-0.5dB 10Hz to Fs/2
    • Crosstalk: <-110dBu @ 1kHz
    • THD+N @ -1dBFS (1kHz): <0.001%
    • Dynamic Range: 121dB A-weighted
    • 1/4” Jack: TIP (Hot), RING (Cold) & SLEEVE (Shield)

    Headphone Output

    • Max Output Level: 11.25dBu
    • Output Impedance: <50Ω
    • Frequency Response: +/-0.5dB 10Hz to Fs/2
    • Crosstalk: -108dBu @ 1kHz
    • THD+N @ -1dBFS (1kHz): <0.001%
    • Dynamic Range: 118dB A-weighted
    • Max Level Into 30ohms: +8.5 dBu, 0.00094% THD+N, 1.66Vpk Power: 86mW
    • Max Level Into 60ohms: 10 dBu, 0.00079% THD+N, 2.55Vpk Power: 104mW
    • Max Level Into 600ohms: 11.2 dBu, 0.00057%THD+N, 3.83Vpk Power: 24mW
    • 1/4” Jack: TIP (Left), RING (Right) & SLEEVE (Shield)

    Written by Ainsley Walker

    Specifications
    Analogue Inputs
    28
    Microphone Inputs
    8
    Analogue Outputs
    24
    Brand
    Audient
    PC Connectivity
    USB-C
